Silicone Structural Sealant Testing Machine for Construction

The building silicone structural sealant testing machine developed and manufactured by Shandong Huayan is mainly used for tensile property tests of various silicone adhesive composites, such as testing mechanical performance indicators including tensile adhesion, elongation, tensile modulus, high-temperature tensile adhesion, and low-temperature tensile adhesion. It meets standards such as JG/T 475-2015, JG/T 471-2015, GB/T 13477-2017, and GB 16776-2005. The equipment system uses closed-loop computer control and features a wide and accurate loading speed and force measurement range, offering high precision and sensitivity in measuring and controlling load and displacement. With the addition of appropriate accessories, this equipment is also suitable for testing in industries such as metal, adhesives, pipes, profiles, aerospace, petrochemicals, waterproof membranes, wire and cable, textiles, fibers, rubber, ceramics, food, pharmaceutical packaging, geotextiles, films, wood, and paper, as well as for quality supervision departments and teaching demonstrations in colleges and universities.

Technical specifications:

Style: Double-column portal type
2. Test force: 50 kN
3. Range: 2% - 100%;
4. Test force accuracy: better than ±1% of the indicated value
5. Test force accuracy: 1N
6. Testing Machine Class: Class 1
7. Displacement resolution: 0.01 mm;
8. Displacement measurement accuracy: ±0.5%;
9. Test space: 600mm (customizable according to customer requirements)
10. Horizontal test space: 650 (customizable according to customer requirements)
11. Displacement speed control range: 0.1 mm/min to 300 mm/min
12. Displacement speed control accuracy: ±0.5%;
13. Testing machine dimensions: approximately 1200mm x 1200mm x 2000mm
14. Testing machine weight: approximately 500KG
15. Appearance: Should comply with GB/T 2611 requirements.
16. Completeness: Meets standard requirements
17. Protection Function: The testing machine is equipped with an overload protection function.
18. Power supply: 220V, 50Hz
