Dragon Bone Mechanical Property Testing Machine

The mechanical property testing equipment for light steel keel used in construction is mainly used for static load pressure testing of light steel keel and tensile property testing of accessories (hangers, connectors). With simple fixtures, it can also test mechanical properties such as tension, compression, bending, shear, tear and peel of metals, nonmetals and composite materials.

GB/T 11981-2008 "Light Steel Framing for Building Construction"

JC/T 558-2007 "Light Steel Framing Accessories for Construction"

JC/T 698-2010 "Gypsum Blocks"

GBT19766-2016 "Natural Marble Building Slabs"

Ceramic Tiles (GBT4100-2015)

JCT746-2007 "Concrete Roof Tiles"

GB/T 228.1-2010 Metallic Materials—Tensile Testing at Ambient Temperature

GB/T 16491-2008 Electronic Universal Testing Machine
Technical specifications:

Style: Double-column portal type
2. Test force: 10 kN (10,000 N)
3. Range: 2%-100%;
4. Test force accuracy: better than ±1% of the indicated value
5. Test force accuracy: 1N
6. Testing Machine Class: Class 1
7. Displacement resolution: 0.01 mm;
8. Displacement measurement accuracy: ±0.5%;
9. Test Space: 600mm (customizable according to customer requirements)
10. Horizontal test space: 1000*1000mm (customizable according to customer requirements)
11. Displacement speed control range: 0.1 mm/min to 300 mm/min
12. Displacement speed control accuracy: ±0.5%;
13. Dimensions of the testing machine: approximately 1200mm × 1200mm × 2000mm
14. Machine weight: Approx. 1000KG
15. Appearance: Should comply with GB/T 2611 requirements.
16. Completeness: Meets standard requirements
17. Protection Function: The testing machine is equipped with an overload protection function.
18. Power supply: 220V, 50Hz
